Working with layers - a headstart of a beginner...

[saint_m]

good day dear experts, hello everyone,


i am currenty workin on some preliminary steps for a new project.

i want to show a little image for illustration.  Therefore i need a image with some dots.

I have a basic-image (which i want to use as a starting point.)


well -i need only the dots - that are blue  - not the green ones and not the yellow ones.

how to achive this:

well i think that i can work here with layers - or "masks" : can ´t i?

that saidL i think that we re able to - let us say "to isolate  a certain amount oif the dots"

So - if i could work with layers - then i would be able to achive  a image where i only have a certain amound of dots left - the (above menitoned) blue ones

How would you do that: - how would you try to achieve that - to make sure that only this blue dots remain.

so the question is:  – how would you approach this, what's the best way to proceed? Should I use layers or masks?

I think it should be possible to isolate a single color here – to focus on the dots with only  one certain color - the blue oner: , so to speak – and extract them - so that those dots are  what remains in the end.

Should I do this with layers (or layers) or masks?





i think that this is a gerneral Beginner question - and yes:  if i can do this - if i achive this - then i guess that i would be able to lots of other things more with GIMP

Loook forward to hear from you

greetings

[denzjos]

Use the 'Select by Colour Tool', set Threshold 25, set the 'Select by Colour' mode to add (second icon from the left below the tekst 'Select by Colour) and click on a few blue dots (dark blue, light blue,... what you want). Then 'Select / Grow' set 2 pixels and copy the result to a new layer and make a new white layer (or the colour you like) below the 'dots' layer.



[saint_m]

hello dear Denzjos

many thanks for the quick reply and for the input  - awesome  - and a great asset of GIMP-knowledge for me.  I am delighted. Your image - it shows great great achivements.

as i understand that  - i can use "Color-Tool"

and within that - i can set the threshold - to a "certain value"

BTW: you


firstly: took the Threshold 25,  and afterwards  you set the 'Select by Colour' mode to add (second icon from the left below the tekst 'Select by Colour)

and afterwards - you

second: click on a few blue dots (dark blue, light blue,...) and then

thirds:  'Select / Grow' set 2 pixels and copy the result to a new layer and make a new white layer (or the colour you like) below the 'dots' layer.


thank you so much. I will try out these steps at the weekend.

you saved my day.

have a great day. - greetings.
Saint_M

BTW:  you earned 10 stars out of 5 possible..
